Specification
Specifications
| Specification | |
|---|---|
| Model | DTEC-C012 |
| Main System | |
|---|---|
| CPU / Chipset | 12th Gen Intel CoreTM i3/i5/i7 processor |
| Memory | 2x DDR5 SO-DIMM 4800 up to 64GB |
| Storage | - 1x M.2 NVMe with PCIe x4 for SSD | - 1x SATA 3.0 |
| Expansion | Optional 1x M.2 Key E 2230 | Support Intel Wi-Fi 6E and Bluetooth Module |
| Display | - 1x HDMI® up to 4K resolution | - 1x DP up to 8K resolution |
| BIOS | AMI uEFI BIOS (SPI ROM) |
| I.O. Ports | |
|---|---|
| USB | - 5x USB 2.0 (Type-A) | - 4x USB 3.2 (Type-A) |
| Audio | Realtek ALC 897 Audio Codec MIC In/Line-out |
| Serial Port | 2x RJ-45 COM ports |
| Ethernet | 2x Intel I226LM With 2.5G Gigabit LAN |
| Mechanical and Environmental | |
|---|---|
| Temperature | Operation Temperature -5°C ~ 40°C | Storage Temperature -40°C ~ 70°C |
| Dimensions (Net) | 152(W) x 196(D) x 44(H) mm |
| Power Input / Consumption | DC 12~24V DC input |
