WLPM-V22 AMD Ryzen™ V1605B 22"
產品介紹
Best Suit for Versatile Industrial Applications
Modular Panel PC Professionals
The Modular Panel PC WLPM-V00 Series with CE/FCC/VCCI class B certified are designed to suit industrial modular solutions. Featuring in flexible panel modulars which is combined WLPM box PC with panel size ranging from 15”/22”/24” to be easy installation, lower overall maintenance fee and scalable capability. WLPM modular panel PC designed with front IP66 water and dust proof that is convenient for factory operations easy to clean. Built with high performance computing power with customization capability, WLPM-V00 series could fully provide high speed data transfer benefits for various requirements; in addition, the housing is engineered to withstand extreme temperatures that make it best suit for versatile industrial automation, factory control, surveillance, smart kiosk, military, communication centers and so on.
- High Computing Power
- Modular Design
- Fanless w/ Smart Thermal Control
- Flexible Configuration for Easy Control
Specification
| Model | WLPM-V22 | ||
|---|---|---|---|
| Main System | |||
| CPU / Chipset | AMD Ryzen CPU, V1605B, QC, 2GHz, 12-25W / SoC | ||
| Graphic | AMD Radeon™ Vega 8 Graphics | ||
| RAM | Dual Channel DDR4 2400 MHz (V1605B/ V1202B) , 32 GB | ||
| OS Support | Win 10 (64 bit) | ||
| Storage | 1 x 2.5” SATA SSD 1 x M.2 M.Key 2242/2260/2280 PCIex2 and SATA for SSD |
||
| Expansion |
1 x M.2 Key E 2230 w/ PCIex1, share USB2.0 for Wireless
1 x mini-PCIe for Full/Half w/ PCIex1
1 x PCIex8 (25W max.)
|
||
| Display Size | 21.5” 16:9 | ||
| Display | 1920 x 1080 (FHD), 170(H) / 160(V), 250 nits (Typ. Center point), CR: 1000 : 1 (Typ) | ||
| Touch Screen | Full Flat Projective Capacitive Touch Panel / Light Transmission: >=86% / Hardness: 7H pencil / Life: 100M times 5 Wire Full Flat Res. Touch / Light Transmission: 80% ± 5% / Hardness: 3H pencil / Life: 35M times |
||
| I.O. Ports | |||
| USB | 2 x USB 3.2 GenII, 2 x USB 2.0 | ||
| COM | 2 x RS232/RS422/RS485 | ||
| LAN | 2 x RJ-45 | ||
| Audio | 2 x 3.5mm phone jack connector (Line-out, Mic-in) | ||
| Video | 3 x DP1.2a | ||
| Control Keys | Rear bottom: Power on/off | ||
| Mechanical and Environmental | |||
| Cooling | Fanless | ||
| Power Input | 1 x DC-in(Jack with locker), DC19V~28V | ||
| Power Adapter | 150W (PSU with PSE) | ||
| Temperature | Operating Temperature: 19V DC Input 0~50℃ (air flow cooling) Storage Temperature: -20~60℃ |
||
| Humidity | Operating & Storage:10% ~ 90%, non-condensing | ||
| IP & IK Rating / Housing | IP66 at front, IK05 / Front bezel is Aluminum, others are SECC with black coating | ||
| Dimensions (Net) | 584.3 mm (H) x 364.6 mm (V) x 121.4 mm (T) | ||
| Weights (Net) | TBD kg (w/o power adapter) | ||
| Mounting | Panel mount (by clamp), VESA (75x75) | ||
| Certification | FCC/CE/VCCI Class B, Canada ICES-003 | ||
Options & Customization
