| Model | WBT-1123 | ||
|---|---|---|---|
| Main Body | |||
| Battery Type | 4S2P Lithium-ion | ||
| Battery Voltage | DC: 14.8 V | ||
| Battery Capacity | 6000 mAh | ||
| Battery Energy | 88.8 Wh | ||
| Battery Pack Cycle life | Percentage of recoverable capacity ≥80% of initial capacity at 800th cycle | ||
| Warranty | Normal use in one year, charge < 500 cycles and charge capacity < 70% | ||
| ContinContinuous charge currenuous charge current | 3100mA ( Max..≤ 6200mA ) | ||
| Continuously discharge current | 1240mA ( max continuous discharge protection ≤ 2300±500mA / 1-5s ) | ||
| Battery LED Indicator | |||
| One LED Flashing | 0%~19% capacity | ||
| One LED Lighting | 20%~39% capacity | ||
| Two LED Lighting | 40%~59% capacity | ||
| Three LED Lighting | 60%~79% capacity | ||
| Four LED Lighting | 80%~99% capacity | ||
| Five LED Lighting | 100% capacity | ||
| LED Indicator in WMP G/H series | |||
| In Charge | Blinking Green | ||
| Full Charge | Green | ||
| Discharge | Blinking Blue | ||
| Low Battery | Quick Blinking Blue | ||
| Not in charge | Normal: blue; Dark: no battery (OSD check battery status) | ||
|
Environmental & Mechanical Characteristics
|
|||
| Temperature |
Operating Temperature charge:0~50℃;discharge:-10~60℃
Storage Temperature
-20~60℃ Less than 1 month
-20~25℃ Less than 12 month
|
||
| Storage Humidity |
<70%@0~20°C, noncondensing
|
||
| Architecture | ABS + Plastic | ||
| Housing | White | ||
| Dimensions (Net: mm) | 172 mm x 82 mm x 22 mm per Battery | ||
| Weights (Net: kg) | 0.45 kg per Battery | ||
| Certification |
|||
| Certification | UL2504, CB, CE, BSMI, PSE, IEC-62133, UN38.3 | ||
