Specification
ModelWTP-8D66-19
Main System
CPU / Chipset Intel® Apollo Lake Celeron Processor J3455 10W / SoC
Graphic Intel® Graphics HD 500
RAM Single channel support 1867MHz DDR3L SODIMM socket, up to 8GB
OS Support Win10 (Optional)
Storage 2.5”SATA HDD drive bay x 1, M.2 SATA III SSD 2280 slot x 1
Expansion M.2(E key 2230) x 1, Mini-PCIe 52 pin x 1
Display Size 19” 5:4
Display 1280 x 1024(SXGA),  170(H) / 160(V), 350 nits (Typ. Center point), CR:1000 : 1 (Typ)
Touch Screen Full flat resistive touch  /  Light Transmission: 80 ± 5% / Hardness: ≧3H
 I.O. Ports
USB 1 x M12 8pin for USB 1/2, 1 x M12 8pin for USB 3/4
COM 1 x M12 8pin/ RS-232, 1 x M12 8pin/ RS-232/ 422/ 485
LAN 1 x M12 8pin for LAN
Control Key  Rear bottom: Power on/off
Mechanical and Environmental
Cooling Fanless
Power Input / Consumption DC 9V~32V / 42.7 W
Power Adapter AC 90~264V / 47 ~ 63 Hz / DC output 12V, 60W (IP68 PSU w/ PSE)
Temperature Operating Temperature: 0~45℃ (12V DC)
Storage Temperature: -20~60℃
Humidity Operating & Storage:10 ~ 90%, non-condensing
IP Rating / Housing IP66 / NEMA4X / IP69K / IK05 / SUS304 stainless steel enclosure, chassis type
Dimensions (Net) 458 mm (H) x 386 mm (V) x 64 mm (T)
Weights (Net) 11.0 kg
Mounting VESA 100, Side mount (M6*2)
Certification CE/ FCC/ VCCI Class B, Canada ICES-003
Options & Customized

Major Options

Add On Parts

1. Wireless LAN or Wireless and BT kit  (Easy Clean and Robust Antenna)
2. M.2 SSD
3. External LAN x 2
4. Waterproof USB 3.0
5. Stainless M12 connector
6. TPM2.0
7. IP67
8. Full Flat PCT Touch Screen IP69K
9. SUS316 Enclosure
10.2.5"SSD

Power Cable

1. Waterproof COM cable, cable length is 2 meters
2. Waterproof USB cable, cable length is 2 meters
3. Waterproof LAN cable, cable length is 2 meters
4. DC input cable
5. Maximum length is 5.2 meters by 2x2m DC cables

Optional kits

1.Wall mount / Table mount bracket

Customized

1.Sunlight readable optical bonding ( Impact Protection Level : IK08 )
2. 1000 nit high brightness LCD
3. LCD Auto dimming
4. 5W/2WSpeaker
5. PoE
6. Second HD for RAID 0,1
7. COM + power 5V or 12V
8. Barcode reader
9. Car ignition power control
